FILTER PRESS
Vertical Multi-stage Centrifugal Pump
for Membrane Squeezing Purpose of Membrane Filter Press
Main Technical Data
| model | Max. power | Capacity | Head | Speed | Inlet/outlet |
| kw | (m³/h) | (m) | (r/min) | ||
| CDM4-16 | 3 | 4 | 129 | 2900 | DN32/PN25 |
| CDM4-19 | 4 | 4 | 153 | 2900 | DN32/PN25 |
| CDM4-22 | 4 | 4 | 178 | 2900 | DN32/PN25 |
| CDM8-14 | 5.5 | 8 | 130 | 2900 | DN40/PN25 |
| CDM8-16 | 5.5 | 8 | 148 | 2900 | DN40/PN25 |
| CDM8-18 | 7.5 | 8 | 167 | 2900 | DN40/PN25 |
| CDM8-20 | 7.5 | 8 | 186 | 2900 | DN40/PN25 |
| CDM10-18 | 7.5 | 10 | 180 | 2900 | DN50/PN25 |
| CDM10-22 | 11 | 10 | 220 | 2900 | DN50/PN25 |
| CDM12-12 | 7.5 | 12 | 121 | 2900 | DN50/PN25 |
| CDM12-14 | 11 | 12 | 141 | 2900 | DN50/PN25 |
| CDM12-16 | 11 | 12 | 162 | 2900 | DN50/PN25 |
| CDM12-18 | 11 | 12 | 183 | 2900 | DN50/PN25 |
| CDM16-12 | 11 | 16 | 141 | 2900 | DN50/PN25 |
| CDM16-14 | 15 | 16 | 166 | 2900 | DN50/PN25 |
| CDM16-16 | 15 | 16 | 189 | 2900 | DN50/PN25 |
